fourier.h File Reference

Bandlimited Fourier waveform stimulus (saw / square / triangle; BLIT, PolyBLEP, miniBLEP). More...

#include "oakfield/operator_split.h"
#include <stdbool.h>
#include <stddef.h>

Include dependency graph for operators/stimulus/fourier.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	SimFourierWaveformConfig
	Configuration for Fourier waveform stimulus. More...

Typedefs
typedef enum SimFourierWaveformShape	SimFourierWaveformShape
	Waveform shapes produced by the Fourier stimulus.
typedef enum SimFourierWaveformMethod	SimFourierWaveformMethod
	Bandlimiting methods used by Fourier waveform synthesis.
typedef struct SimFourierWaveformConfig	SimFourierWaveformConfig
	Configuration for Fourier waveform stimulus.

Enumerations
enum	SimFourierWaveformShape { SIM_FOURIER_WAVEFORM_SAW = 0 , SIM_FOURIER_WAVEFORM_SQUARE , SIM_FOURIER_WAVEFORM_TRIANGLE }
	Waveform shapes produced by the Fourier stimulus. More...
enum	SimFourierWaveformMethod { SIM_FOURIER_METHOD_BLIT = 0 , SIM_FOURIER_METHOD_POLYBLEP , SIM_FOURIER_METHOD_MINIBLEP }
	Bandlimiting methods used by Fourier waveform synthesis. More...

Functions
SimResult	sim_add_stimulus_fourier_operator (struct SimContext *context, const SimFourierWaveformConfig *config, size_t *out_index)
	Register a bandlimited Fourier waveform stimulus operator.
SimResult	sim_stimulus_fourier_config (struct SimContext *context, size_t operator_index, SimFourierWaveformConfig *out_config)
	Copy the current Fourier waveform configuration from a registered operator.
SimResult	sim_stimulus_fourier_update (struct SimContext *context, size_t operator_index, const SimFourierWaveformConfig *config)
	Replace or renormalize a registered Fourier waveform configuration.

Detailed Description

Bandlimited Fourier waveform stimulus (saw / square / triangle; BLIT, PolyBLEP, miniBLEP).

Typedef Documentation

SimFourierWaveformConfig

typedef struct SimFourierWaveformConfig SimFourierWaveformConfig

Configuration for Fourier waveform stimulus.

All frequencies are in Hz. Phase is normalized to [0,1).

Enumeration Type Documentation

SimFourierWaveformMethod

enum SimFourierWaveformMethod

Bandlimiting methods used by Fourier waveform synthesis.

Enumerator
SIM_FOURIER_METHOD_BLIT	Bandlimited impulse train method.
SIM_FOURIER_METHOD_POLYBLEP	Polynomial bandlimited step method.
SIM_FOURIER_METHOD_MINIBLEP	Windowed-sinc miniBLEP method.

SimFourierWaveformShape

enum SimFourierWaveformShape

Waveform shapes produced by the Fourier stimulus.

Enumerator
SIM_FOURIER_WAVEFORM_SAW	Sawtooth waveform.
SIM_FOURIER_WAVEFORM_SQUARE	Square waveform.
SIM_FOURIER_WAVEFORM_TRIANGLE	Triangle waveform.

Function Documentation

sim_add_stimulus_fourier_operator()

SimResult sim_add_stimulus_fourier_operator	(	struct SimContext *	context,
		const SimFourierWaveformConfig *	config,
		size_t *	out_index
	)

Register a bandlimited Fourier waveform stimulus operator.

The implementation copies and normalizes config, initializes the requested waveform state, and registers the operator on the target field.

Parameters

	context	Simulation context that will own the operator.
	config	Optional waveform configuration; NULL selects normalized defaults.
[out]	out_index	Optional destination for the registered operator index.

Returns

SIM_RESULT_OK on success, or an error code from validation, allocation, or split-operator registration.

sim_stimulus_fourier_config()

SimResult sim_stimulus_fourier_config	(	struct SimContext *	context,
		size_t	operator_index,
		SimFourierWaveformConfig *	out_config
	)

Copy the current Fourier waveform configuration from a registered operator.

Parameters

	context	Simulation context containing the operator.
	operator_index	Index returned by sim_add_stimulus_fourier_operator().
[out]	out_config	Receives the operator's normalized configuration.

Returns

SIM_RESULT_OK on success, SIM_RESULT_INVALID_ARGUMENT for NULL pointers, SIM_RESULT_NOT_FOUND for a missing operator, or SIM_RESULT_INVALID_STATE when the operator has no stimulus state.

sim_stimulus_fourier_update()

SimResult sim_stimulus_fourier_update	(	struct SimContext *	context,
		size_t	operator_index,
		const SimFourierWaveformConfig *	config
	)

Replace or renormalize a registered Fourier waveform configuration.

Passing NULL for config keeps the existing configuration and reapplies normalization. A successful update refreshes waveform state and invalidates the scheduler plan.

Parameters

context	Simulation context containing the operator.
operator_index	Index of the Fourier waveform operator to update.
config	Optional replacement configuration.

Returns

SIM_RESULT_OK on success, or an error code if lookup or state validation fails.
