Opaque-ish mapping handle used by input/output mapping paths. More...
#include <neural_tensor_map.h>
Public Attributes | |
| SimNeuralTensorView | view |
| SimNeuralTensorMapMetrics | metrics |
| SimNeuralTensorMapConfig | config |
| const SimField * | field_const |
| SimField * | field_mut |
| void * | scratch |
| size_t | scratch_bytes |
| uint8_t | field_rank |
| uint8_t | field_channel_axis |
| uint8_t | field_spatial_rank |
| uint8_t | field_spatial_axes [3] |
| bool | has_field_channel_axis |
| bool | output_mode |
| bool | active |
Detailed Description
Opaque-ish mapping handle used by input/output mapping paths.
Call sim_neural_tensor_mapping_release after use. For output mappings created by sim_neural_tensor_map_output, call sim_neural_tensor_unmap_output before release when fallback copy was used.
Member Data Documentation
◆ active
| bool SimNeuralTensorMapping::active |
True while the mapping owns/references live resources.
◆ config
| SimNeuralTensorMapConfig SimNeuralTensorMapping::config |
Normalized mapping policy.
◆ field_channel_axis
| uint8_t SimNeuralTensorMapping::field_channel_axis |
Resolved channel axis in field coordinates.
◆ field_const
| const SimField* SimNeuralTensorMapping::field_const |
Borrowed source field for input mappings.
◆ field_mut
| SimField* SimNeuralTensorMapping::field_mut |
Borrowed mutable field for output mappings.
◆ field_rank
| uint8_t SimNeuralTensorMapping::field_rank |
Rank of the mapped field layout.
◆ field_spatial_axes
| uint8_t SimNeuralTensorMapping::field_spatial_axes[3] |
Field axes corresponding to tensor spatial dimensions.
◆ field_spatial_rank
| uint8_t SimNeuralTensorMapping::field_spatial_rank |
Number of spatial axes in the mapped field.
◆ has_field_channel_axis
| bool SimNeuralTensorMapping::has_field_channel_axis |
True when the field exposes an explicit channel axis.
◆ metrics
| SimNeuralTensorMapMetrics SimNeuralTensorMapping::metrics |
Copy/transform costs observed during mapping.
◆ output_mode
| bool SimNeuralTensorMapping::output_mode |
True when mapping is intended for write-back.
◆ scratch
| void* SimNeuralTensorMapping::scratch |
Owned fallback tensor buffer, released by mapping_release().
◆ scratch_bytes
| size_t SimNeuralTensorMapping::scratch_bytes |
Allocated byte size of scratch.
◆ view
| SimNeuralTensorView SimNeuralTensorMapping::view |
Tensor view exposed to the backend.
The documentation for this struct was generated from the following file:
